Safe Operation Regulations of Automatic Folder Gluer

In order to enable everyone to have a safe operating environment, Gaoke deliberately explains some safe operating procedures for automatic folder-gluing machines, which can not only ensure the safety of their employees, but also improve product quality, reduce production costs, and increase production efficiency.

1. The scope of the user: all operators who have been trained in the folder-gluer

2. Safe operation
    Before turning on the power, you need to carefully check the mechanical parts and safety protection devices to ensure that there are no abnormalities. Fill the parts that need lubrication according to the regulations.
    Turn on the power, check whether the switches of each part are normal, check the mechanical protection device and whether there are sundries around, whether the screws of important parts are tightened, and there must be no looseness, and whether the air supply pressure has reached the working level. state.
    The protective device cannot be disassembled except for the maintenance protective device, and the protective device must be installed when it needs to be used for production.
    When the governor is stopped, it is forbidden to adjust the speed, so as not to cause serious wear to the belt
    When the machine is operating, do not touch any moving parts with your hands (non-workers are forbidden to approach the machine)
    In the event of a personnel accident caused by machinery (please prohibit unrelated personnel from approaching to avoid secondary injuries), please ask professionals for assistance.

3. Strictly demand the quality requirements of pasting boxes.
    Adhesive alignment should be accurate, and no skew phenomenon should appear.
    Firm bonding, no degumming, no inner and outer laps.
    No scratches, or leave obvious scratches and stains on the printed surface.

4. daily maintenance
    At the end of the work day, there must be no water left in the air compressor cylinder, and it must be drained cleanly. (And the atomized oil in the oil mist cup needs to be checked every day, not less than the rated value)
    After finishing the work, press the stop button, slowly reduce the speed of the machine, and then turn off the power of the machine.
    Clean the machine. No items can be left on the machine. Clean the ground around the machine to make it clear. The moving parts of the machine need to be lubricated with a small amount of oil.
    After the above steps are completed, put the tool back in place, and fill in the work report for the machine.

5. operation process
    Adjust the width of the glue box baffle so that the two sides are parallel, so that the semi-finished color box to be produced can be just put down, and the distance between the two side baffles should be less than 1mm from the color box, and then adjust the limit bolts to ensure that each product can be smooth Passed, and no binding phenomenon appeared.
    Adjust the slope and height of the bracket in the paste box area to make each product move forward smoothly and ensure that there is no binding phenomenon. After pressing, adjust the auxiliary pipe guide rail and flow wheel to make the size suitable for the paste color box specification.
    Adjust the glue tank and check whether the glue in the glue tank is sufficient. Generally, the appropriate amount is 80% of the amount of glue immersed in the rubber wheel, and then adjust the glue tank and the glue position.
    Turn on the power, turn on the power switch, the main motor switch and the vibration switch, press the "Run" and "Inch" keys after mechanical adjustment, and press the "Paper" key to debug the machine and check the performance of the machine. If there is any abnormality, take measures immediately.
    After the debugging is completed, put in 5-10 sheets of paper to test the machine, and after confirming all the parameters, the paper can be discharged normally.
    Matters needing attention: always pay attention to the state of pasting and feeding paper, and there must be no over-line, offline or misalignment, otherwise it will affect the appearance and molding effect of the color box.
    Operate strictly in accordance with the operating procedures, and do not allow irrelevant personnel to approach the machine, so as not to cause an irreversible situation.
